100 Mounting Plate — Euro Screws

A precision-engineered mounting plate designed for consistent hinge alignment across frameless cabinetry installations.

Constructed from cold-rolled steel with a standard zinc finish, this mounting plate delivers the dimensional accuracy required for professional cabinet fitting. The Euro screw fixing pattern ensures a secure, repeatable connection to the cabinet side panel, while the 0mm and 3mm height variants accommodate different overlay configurations without shimming. Compatible with the 100-series hinge range.

Product Details

• Material: Cold-rolled steel
• Finish: Zinc-plated
• Height options: 0mm, 3mm
• Mounting type: Euro screw (Screw-on, Euro screws, Split-dowels)
• Compatible with: 100-series concealed hinges
• Weight: 30g per plate

Best For

Suited to frameless kitchen and bathroom cabinetry where hinge height adjustment is required during installation. Resolves overlay misalignment on standard 32mm system carcasses. A reliable component for both new builds and cabinet refits requiring precise door positioning.
