143 Series Hinge | 172° Full Overlay

A wide-opening concealed hinge engineered for full overlay cabinetry where unrestricted access is a functional requirement.

Constructed from hardened steel with a precision-machined cup mechanism, the 143 Series delivers a consistent 172° opening arc — eliminating the door as an obstruction when accessing deep pantry units or corner cabinets. The 0mm cranking specification suits full overlay door configurations, and three mounting variants accommodate screw-on, dowel, and knock-in assembly workflows without modification to the cabinet body.

Product Details

• Material: Hardened steel with zinc alloy components
• Opening angle: 172°
• Overlay: Full overlay (0mm cranking)
• Drill pattern: Compatible with 45mm and 52mm boring configurations
• Mounting options: Screw On, With Dowels, Knock In
• Weight per hinge: 70g
• Pack quantity: Box of 100

Best For

Suited to pantry cabinets, tall units, and corner applications where a standard 110° hinge restricts access to interior fittings. The bulk pack format makes it a practical specification for cabinet manufacturers and joinery workshops running production volumes. Knock-in and dowel variants integrate directly into CNC-drilled panels without secondary fixings.
